RCO-3000-KBL Industrial Computer with 7th Gen Intel® Core™ Processor and Q170 PCH

Product image 1
1 / 9

RCO-3000-KBL Industrial Computer with 7th Gen Intel® Core™ Processor and Q170 PCH

  • LGA 1151 socket for 6th/7th Gen. Intel® Core™ i7/i5/i3 or
    Pentium® / Celeron® Desktop Processor
  • Intel® Q170 chipset
  • 2x DDR4 1866/2133MHz SODIMM. Max. up to 32GB
  • Intel® HD Graphics 530 / 630
  • Triple independent display supported by 1x DVI-I,
    1x DisplayPort, 1x HDMI (Optional)
  • 2x Intel® GbE supporting Wake-on-LAN and PXE
  • 2x internal 2.5" SATA HDD bay with RAID 0, 1, 5, 10 support,
    2x mSATA (shared by 2x Mini PCIe), 1x CFast
  • 2x full-size Mini PCIe (shared by 2x mSATA) for communication or
    expansion modules, 2x external SIM socket
  • 4x RS-232/422/485 (w/ 2x internal),
    6x USB 3.0, 2x USB 2.0 (internal)
  • 8x DI + 8x DO with isolation
  • 9 to 50VDC wide range power input supporting AT/ATX mode
  • -25°C to 60°C extended operating temperature
$255.00

Original: $850.00

-70%
RCO-3000-KBL Industrial Computer with 7th Gen Intel® Core™ Processor and Q170 PCH—

$850.00

$255.00

Product Information

Shipping & Returns

Description

  • LGA 1151 socket for 6th/7th Gen. Intel® Core™ i7/i5/i3 or
    Pentium® / Celeron® Desktop Processor
  • Intel® Q170 chipset
  • 2x DDR4 1866/2133MHz SODIMM. Max. up to 32GB
  • Intel® HD Graphics 530 / 630
  • Triple independent display supported by 1x DVI-I,
    1x DisplayPort, 1x HDMI (Optional)
  • 2x Intel® GbE supporting Wake-on-LAN and PXE
  • 2x internal 2.5" SATA HDD bay with RAID 0, 1, 5, 10 support,
    2x mSATA (shared by 2x Mini PCIe), 1x CFast
  • 2x full-size Mini PCIe (shared by 2x mSATA) for communication or
    expansion modules, 2x external SIM socket
  • 4x RS-232/422/485 (w/ 2x internal),
    6x USB 3.0, 2x USB 2.0 (internal)
  • 8x DI + 8x DO with isolation
  • 9 to 50VDC wide range power input supporting AT/ATX mode
  • -25°C to 60°C extended operating temperature
